Banjo M332PIHYW 3 inch flange wet seal hydraulic driven cast iron pump 1360 lpm 32 m head

Banjo M332PIHYW 3 inch flange wet seal hydraulic driven cast iron pump
21 hp Tyrone UM16 hydraulic motor
Carbon ceramic mechanical seal
Wet seal chamber
Self-priming
In-built check valve
1360 lpm (360 gpm)
32 m head
3.2 bar (46 psi)
Hydraulic motor fluid requirements:
34 lpm (9 gpm) min
49 lpm (13 gpm) max
41 bar (600 psi) min
207 bar (3000 psi) max
Dimensions (excluding handle):
490 x 289 x 270 mm (L x W x H)
Applications include:
Pumping Bentonite
Hydro seeding
Spray-on liquid grass
Liquid fertiliser
Effluent
